SMART TECHNOLOGY FOR SECURITY AND SURVEILLANCE.
Key Feature
- 5MP + 76.8K Dual Thermal AI Camera
- Supports Intelligent Video Analysis Events (Line/Intrusion/Queue Management)
- Maximum Resolution 2592 (Horizontal) X 1944 (Vertical) / 30fps + 320 (Horizontal) X 240 (Vertical) / 9fps
- Horizontal Field of View 82 degrees + 56 degrees / Fixed Lens
- Day & Night(ICR)/IR Visibility up to 25 meters
- Backlight Compensation (WDR)
- Uncooled VOx 12-micron Thermal Sensor
- Temperature Measurement Range -40°C to 330°C
- Detection/Recognition/Identification Range 333m/83m/48m
- Color Temperature Display Support
- SD/SDHC/SDXC Memory Slot
- PoE IEEE 802.3af/Class3
- IP66/IK09
- Built-in Heater
Specifications
| Video | |
|---|---|
| Image Sensor |
|
| Channels |
1
|
| Total Pixel |
2704(H) X 2104(V) + 320(H) X 240(V)
|
| Max Resolution |
2592(H) X 1944(V) + 320(H) X 240(V)
|
| MIN. Illumination |
COLOR: 0.16Lux
BW: 0Lux with IR
|
| Only installer Video Output |
1 [CVBS 1.0V p-p (75Ω)]
|
| S/N(signal/noise) Ratio |
50dB
|
| Scanning Mode |
Progressive Scan
|
| Lens | |
|---|---|
| Focal Length |
4.0mm + 4.0mm
|
| Aperture |
F 2.0 + F1.0
|
| Lens Type |
Fixed
|
| IRIS Type |
Auto Exposure
|
| Horizontal Angle |
H : 82.3°, V : 58.8° + H : 56°, V : 42°
|
| Pan / Tilt / Zoom |
Zoom : Fixed
|
| Operational | |
|---|---|
| Shutter Speed |
Auto / Manual (1/15 ~ 1/32000)
Anti-Flicker
Slow Shutter(1/2,1/3,1/5,1/6,1/7.5, 1/10)
|
| Auto Gain Control (AGC) |
Auto
|
| Day & Night |
TDN (True Day & Night)
|
| Digital Noise Reduction |
3D DNR
|
| Wide Dynamic Range (WDR) |
WDR(2x)
|
| Dynamic Range |
120dB or above
|
| LEDs |
H2IR
|
| LED Distance |
80ft(25m)
|
| Privacy Zone |
Yes
|
| Function |
Motion-Detection
Mirror&Flip
|
| Intelligent Video Analytic | |
|---|---|
| AI Intelligent Video Analytic |
Yes
|
| VCA Pro AI |
Intrusion Detection
Zones&lines
Tamper Detection
Appear Filter
Disappear Filter
Dwell Filter
Enter Filter
Exit Filter
Stopped Filter
Counting
Counting Lines
Object Color
Direction Filter
Logical Rules
Tailgating Filter
DL People Tracker
DL Object Tracker
Metadata
|
| Encoder (video & audio) | |
|---|---|
| Video Compression |
H.264
H.265
MJPEG
|
| Support Resolution |
5M +Thermal
H.265 : 2592x1944/2560x1440/1920x1080/1280x720/800x600/704x576/704x480/640x480/640x360/352x288/352x240 + 640x480/320x240 H.264 : 2592x1944/2560x1440/1920x1080/1280x720/800x600/704x576/704x480/640x480/640x360/352x288/352x240 + 640x480/320x240 MJPEG : 1920x1080/1280x720/800x600/768x432/704x576/704x480/640x480/640x360/352x288/352x240 + 640x480/320x240 |
| Intelligent Codec |
Yes
|
| Multiple Profile Streaming Performance |
Triple Streaming(3rd Only MJPEG)
|
| Video BitRate |
100Kbps~25Mbps
|
| Bitrate Control |
Multi Streaming CBR/VBR at H.264,H.265 (Controllable frame rate and Bandwidth)
|
| Video Bitrate extra comment |
Multi-rate for Preview and Recording
|
| Audio Compression |
G.711 ulaw
|
| Special Feature |
Dynamic ROI(Region of Interest)
|
| I/O & Event | |
|---|---|
| Audio In / Out |
1 Line Input[1.0Vrms, 3K ohm]/1 Line Output
|
| Alarm In / Out |
1 Line/1 Line
|
| Mic |
No
|
| Event Trigger |
Motion Alarm
Network Disconnection
Temperature Critical
Illegal Login
Schedule
Sensor Detection
|
| Event Notification |
FTP
E-Mail
Alarm Out
SD Card
|
| Network | |
|---|---|
| Ethernet |
RJ45 (10/100Base-T)
|
| Protocol |
TCP/IP
UDP
AutoIP
RTP(UDP/TCP)
RTSP
NTP
HTTP
HTTPS
SSL
DNS
DDNS
DHCP
FTP
SMTP
ICMP
SNMPv1/v2/v3(MIB-2)
ONVIF
|
| Security |
HTTPS(SSL)
IP filtering
802.1x
Digest Authentication
|
| Application Programming I/F |
CGI API
ONVIF
|
| Web viewer |
MS Edge®
Google Chrome®
|
| Video management software (VMS) |
DW Spectrum® IPVMS
|
| Support languages |
English
Korean
Japanese
|
| Edge storage |
Micro SD
Micro SDHC
Micro SDXC
|
| SD Card Socket |
1
|
| Electrical | |
|---|---|
| Power Requirement |
|
| Power consumption |
|
| Environmental | |
|---|---|
| Operating Temperature |
-40℃ ~ 50℃
|
| Cold Start |
-40℃
|
| Operating Humidity |
10-90% RH(Non-Condensing)
|
| Vandal Proof Casing |
IK09
|
| IP Rating |
IP66
|
| Other Certification |
FCC
CE
ROHS
UL
|
| Mechanical | |
|---|---|
| Housing Model |
BM3
|
| Housing |
|
| Material |
Aluminum-Die Casting
|
| Color |
White
|
| Dimensions (W x D x H) |
242.3mm
96.7mm
|
| Weight |
0.98kg
|
